HXB-165S multi stations bolt part former
HXB-165S multi stations bolt part former
Specifications of five stations bolt parts former
| Specifications | Unit | HXB-165S |
| Forging stations | No. | 5 |
| Forging force | Kgs | 360000 |
| Max. output | Pcs/Min. | 80 |
| Max. cut off diameter | Mm | 23 |
| Max. cut off length | Mm | 205 |
| Main motor | Kw | 75 |
| P.K.O stroke | Mm | 40 |
| K.O stroke | Mm | 165 |
| Die pitch | Mm | 126 |
| Cut off die diameter | Mm | 75 |
| Punch die dimension | Mm | 75*180 |
| Main die dimension | Mm | 108*205 |
| Nominal bolt size | Mm | 10-16 |
| Length under head | Mm | 30-160 |
| Appro. weight | Kgs | 56000 |
| Appro. floor area | M | 12*4.42*2.83 |
